$949 inc gst

WB20 WATER PUMP

ENGINEERING EXPERTISE

Drawing on decades of engineering advancements, the Honda GX120 engine that powers the WB20 ensures easy starting, easy usage, outstanding fuel economy, low emissions and long-lasting durability.

With oil alert and rubber mounts, the full frame type provides stability and delivers smooth running with less vibration. The result is a reliable, long-lasting pump that will perform time after time.

PERFORMANCE

With capacity to deliver 600 litres per minute, this 2″ Volume Water Pump has a maximum suction head of 8m and a maximum total head of 32m. Like so many other Honda products, the WB20 starts first time, every time with Honda’s famous one pull easy start system.

It runs on unleaded fuel, so you’ll never have to mix oil and petrol again. The result? An environmentally-friendly pump with low emissions & fuel consumption.

Powerful output – Honda GX120 engine
Cast iron volute – Reduces case wear
Oil alert system – Shuts off engine when low oil is detected
Heavy duty full frame – Added Protection

Specifications

WB20 2″ WATER PUMP Image

Engine

Product Code

WB20XT4DRXU

Pump Type

Centrifugal volume pump

Engine

GX120

Displacement

118cc

Oil Alert

Yes

Fuel

Unleaded

Total Head (m)

32

Suction Head (m)

8

Max Discharge Capacity

600 litres/min

Self Priming Time (at 5m)

110 sec

Fuel Consumption

1 l/hr

Mounting

Rubber

Hose Band/Stainer

Yes

Fuel Tank Capacity

2.5l

Discharge Port Diameter (mm)

50

Suction Port Diameter (mm)

50

Length (mm)

455

Width (mm)

365

Height (mm)

420

Dry Weight (kg)

21
